JKM NEMA17 2phase 42mm Lead Screw Stepper Motor Double Stack Captive Hybrid Linear Actuators

Name: JKM NEMA17 2phase 42mm Lead Screw Stepper Motor Double Stack Captive Hybrid Linear Actuators
Brand: Jkongmotor
Price: 65 USD

Quality JKM NEMA17 2phase 42mm Lead Screw Stepper Motor Double Stack Captive Hybrid Linear Actuators wholesale

Brand Name : Jkongmotor

Model Number : 43H4A-05-200

Certification : Ce, rohs, Iso

Place of Origin : China

MOQ : 3-10pcs

Price : 65-75

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000PCS/month

Packaging Details : carton

Warranty : 3months-1year

Place of OPlace of Originrigin : China

Model No. : 43H4A-05-200

Type : Hybrid Stepper Motor

Current/Phase : 0.7A

Prduct Type : Nema 17 Captive Linear Actuators

Rated Voltage : 5.0V

Lead Screw Diameter : Φ6.35mm

Lead Screw Lead : 1.5875mm

Linear Travel Per Step : 0.0079mm/step

Resistance : 7.2Ω

MOQ : 10pcs

Contact Now

HAYDON BALL SCREW HYBRID LINEAR STEPPER MOTORS FOR

ROUGH DIAMOND PLANNER MACHINE- MAGNUS SARIN MACHINE

Product Description

item	value
Warranty	3months-1year
Place of Origin	China
Brand Name	Jkongmotor
Model Number	JK42H2A5007K4-22
Phase	2
Type	Hybrid
Current / Phase	0.7A
Product Type	Nema 17 Captive Linear Actuators
Model Name	JK42H2A5007K4-22
Phase No	2 Phase
Rated Voltage	5.0V
Step Angle	1.8Degree
Lead Screw Diameter	Φ6.35mm
Lead Screw Lead	1.5875mm
Linear Travel Per Step	0.0079mm/step
Resistance	7.2Ω
Minimal Thurst /300pps	10KG

Product Parameters:

Brand:Jkongmotor
 Product Type: Nema 17 Captive Linear Actuators
 Model Name: JK42H2A5007K4-22
 Phase No.: 2 Phase
 Step Angle: 1.8Degree
 Rated Voltage: 5.0V
 Current: 0.7A
 Resistance: 7.2Ω
 Inductance: 8.7mH
 Lead Screw Diameter: Φ6.35mm
 Lead Screw Lead: 1.5875mm
 Linear Travel Per Step: 0.0079mm/step
 Leads No.: 4 leads
 Insulation resistance: 100MΩ (500VDC)
 Heat Rise: 80℃
 Minimal Thurst /300pps: 10KG
 Noted: This motor can replace Haydon motors

Product Features:

It has a threaded drive screwheld mostly inside the motor body which connected to a spline.
It has a built in anti-rotation though the use of a spline shaft that allows it to extend and retact as a unit with no requirements for additional anti-rotation.
The captive actuator is designed for shorter strokes up to about three inches, the basic design is least tolerant of system misalignment and is the most protective actuator style, beacuse it is self contained. The captive has the longest basic body style.

JKM NEMA17 2phase 42mm Lead Screw Stepper Motor Double Stack Captive Hybrid Linear Actuators

Changzhou Jkongmotor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.JKONGMOTOR warmly welcome 'OEM' & 'ODM' cooperations and other companies to establish long-term cooperation with us.
 Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.

Product Tags:

JK42H2A5007K4-22 Captive Linear Actuators

2phase Nema 17 Captive Linear Actuators

1.8Degree Nema 17 Captive Linear Actuators
